Broxap Door Barrier with Tapping Bar DDA Compliant is a heavy duty barrier for non-powered doors, designed to support accessibility and assist visually impaired users. Made from mild steel or stainless steel, with options for a round tapping rail or flat tapping plate, it meets BS8300-1:2018 and BS8300-2:2018 standards for DDA compliance.

  • Barrier for non-powered doors with integrated tapping bar or plate for DDA compliance
  • Assists visually impaired users with a tactile element at 100mm or floor level
  • Made from mild steel (galvanised or powder coated) or stainless steel grades 304/316
  • Root fixed installation with 300mm below ground
  • Customisable tapping bar or plate and finish options
  • Suitable for EV charging areas and public access points

Applications

  • Entrances to public buildings
  • EV charging stations
  • Schools and educational facilities
  • Healthcare environments
  • Retirement and residential complexes
  • Transport hubs

Dimensions

Above ground height 900mm

Overall height 1200mm

Width 800mm

Tube diameter 48mm

Materials

Mild steel

Stainless steel grade 304

Stainless steel grade 316

Colours

Cobalt Blue (RAL 5013), Duchess Blue (BS 4800 20-C-40), Goose Grey (BS 4800 00-A-05), Green (RAL 6005), Holly Green (BS 4800 14-C-39), Jet Black (RAL 9005), Sky Blue (RAL 5015), Traffic Red (RAL 3020), Traffic White (RAL 9016), Traffic Yellow (RAL 1023), White Aluminium (RAL 9006), Anthracite Grey (RAL 7016), Nimbus Grey (10 A 07)

Finish

Hot dip galvanised to BS EN ISO 1461

Galvanised and polyester powder coated

Stainless steel 240 grit matt satin polished

Options and variations

48mm diameter tubular tapping rail at 100mm from floor

150mm wide flat tapping plate at floor level

Installation

Root fixed as standard (300mm below ground)

Accreditations

Complies with BS8300-1:2018 and BS8300-2:2018

Meets Department for Transport Inclusive Mobility guidance (with 150mm tapping bar)
