GEZE Slimdrive SC is an automatic curved sliding door system designed for semi-curved entrances and vestibule systems, with a slim 7 cm drive height and quiet, low-wear operation.

  • Automatic curved sliding door system for semi-curved and vestibule entrances

  • Drive height of 7 cm for discreet installation

  • Quiet direct current drive with low wear

  • Opening widths from 800 to 3000 mm, door leaf weights up to 120 kg

  • Network integration via BACnet and independent error recognition

  • Emergency opening with integrated rechargeable battery

  • Self-cleaning roller carriage reduces maintenance

Applications

  • Interior and exterior doors with high access frequency

  • Representative building entrances with large glass façades

  • Vestibule systems combined with linear sliding doors

Dimensions

Opening width: 800–3000 mm

Clear passage height: up to 3000 mm

Canopy height (min): 75 mm

Leaf weight (max): 120 kg per leaf

Radius (min): 1000 mm

Performance

Adjustable opening and closing speed

Barrier-free operation

Independent error recognition and recording

Materials

10 mm laminated safety glass (LSG), special glass on request

22 mm panel lining for side elements

Colours

Powder-coated to RAL, anodised light alloy, colour anodised to sample, polished or grit 240 stainless steel, special coatings on request

Finish

Powder-coated, anodised, polished stainless steel, grit 240 stainless steel

Options and variations

Double entrance, corner door, arc, semicircle configurations

Mechanical and electrical locks (optional)

Optical sheet metal, waterproof, or glass roof structures

Entrance mat and hot-air curtain system options

Special functions on request

Accreditations

DIN 18650

EN 16005

TÜV type approval certificate
