Suitability Aerobics
Ball sports
Dance
Exhibitions
Gyms
Multi-games areas
Performance
Installation Permanent
Elasticity Combined elastic
Sub-layer construction Sandwich panels
Surface finish EPDM rubber
Resilient flooring
Support services Design




SPORTEC® UNI Sandwich Classic combines a floor covering with an elastic underlay for high shock absorbance on indoor sports floors.

This combination prevents damage to joints and other injuries and is therefore particularly recommended for indoor sports facilities in schools, leisure centres and multi-purpose buildings.

The elastic layer (SPORTEC® Standard) and the floor covering (SPORTEC® UNI Classic) are supplied in rolls and installed separately. First, the elastic layer is glued to the substructure. After the adhesive has fully cured, the floor covering is glued to the elastic layer.

Key benefits

  • High shock absorbance
  • Prevents injury and damage to joints
  • Excellent durability
  • High resistance to mechanical wear
  • Large range of colours
  • Walking comfort
  • Effective impact and noise reduction
  • Complies with VOC emission requirements for indoor air
  • Cfl-s1(B1) fire resistant

Technical data

Material
Top layer: fine-grain EPDM colour granules, PU-elastomer bonded
Elastic layer: fine-grain recycled rubber tyre granules PU-elastomer bonded

Roll size
Top layer: 30m (L) x 1250mm (W) x 4mm (t)
Elastic layer: 30m (L) x 1500mm (W) x 4mm (t)
Other thicknesses and lengths on request.

Tolerances: width ± 1.5%, length ± 1.5%, thickness ± 0.3mm.

Material weight per m2
Top layer: approx. 5.2 kg/m²
Elastic layer: approx. 3.1 kg/m²

Colour options
Red, blue, light grey, beige, dark grey
Other colours available on request.

Product testing
(download product data sheet for full details)

Hardness: 60±5 Shore A (DIN 53505)
Abrasion: max. 450 mm3 (DIN 53516)
Slip resistance: R 9 (DIN 51130)
Fire resistance: Cfl-s1(B1) (EN 13501-1)
VOC emission rating: AFSSET rating A+, DIBt and AgBB compliant


SPORTEC® UNI Sandwich Classic combines a floor covering with an elastic underlay for high shock absorbance on indoor sports floors.

This combination prevents damage to joints and other injuries and is therefore particularly recommended for indoor sports facilities in schools, leisure centres and multi-purpose buildings.

The elastic layer (SPORTEC® Standard) and the floor covering (SPORTEC® UNI Classic) are supplied in rolls and installed separately. First, the elastic layer is glued to the substructure. After the adhesive has fully cured, the floor covering is glued to the elastic layer.

Key benefits

  • High shock absorbance
  • Prevents injury and damage to joints
  • Excellent durability
  • High resistance to mechanical wear
  • Large range of colours
  • Walking comfort
  • Effective impact and noise reduction
  • Complies with VOC emission requirements for indoor air
  • Cfl-s1(B1) fire resistant

Technical data

Material
Top layer: fine-grain EPDM colour granules, PU-elastomer bonded
Elastic layer: fine-grain recycled rubber tyre granules PU-elastomer bonded

Roll size
Top layer: 30m (L) x 1250mm (W) x 4mm (t)
Elastic layer: 30m (L) x 1500mm (W) x 4mm (t)
Other thicknesses and lengths on request.

Tolerances: width ± 1.5%, length ± 1.5%, thickness ± 0.3mm.

Material weight per m2
Top layer: approx. 5.2 kg/m²
Elastic layer: approx. 3.1 kg/m²

Colour options
Red, blue, light grey, beige, dark grey
Other colours available on request.

Product testing
(download product data sheet for full details)

Hardness: 60±5 Shore A (DIN 53505)
Abrasion: max. 450 mm3 (DIN 53516)
Slip resistance: R 9 (DIN 51130)
Fire resistance: Cfl-s1(B1) (EN 13501-1)
VOC emission rating: AFSSET rating A+, DIBt and AgBB compliant
