Advances in clay tile technology means that the Hawkins single camber range combines heritage with the most modern firing techniques. The result is a unique colour range at an affordable price.

The new fired sienna weathered-effect tile offers a reclaimed weathered finish with the benefits of a new tile.

Key features

  • A heritage brand with a strong colour range and extra versatility thanks to market leading performance
  • Affordable price making them a real option for any roofing project
  • 5 colours available in the range including the unique fired sienna weathered effect finish
  • A 'Very Good' certification for BES 6001 (all clay plain tiles)
  • 30° minimum pitch for greater design flexibility
  • Excellent environmental credentials with a BRE Green Guide rating of A+

Colours

  • Blue Smooth
  • Dark Heather
  • Fired sienna
  • Staffordshire Blue
  • Staffordshire Mixture

Technical data

  • Size of Tile 265mm x 165mm
  • Minimum Pitch 30°
  • Maximum Pitch 90°
  • Minimum Headlap 65mm (roof) 37.5mm (vertical)
  • Maximum Gauge 100mm (roof) 115mm (vertical)
  • Cover Width 165mm (nominal)
  • Covering Capacity 60 tiles/m² at 100mm gauge (roof) 53 tiles/m² at 115mm gauge (vertical)
  • Weight of Tiling 64kg/m² (0.63 kN/m²) at 100mm gauge (roof) 56g/m² (0.55 kN/m²) at 115mm gauge (vertical)
  • Battens Required 10.0 lin.m/m² at 100mm gauge (roof) 8.7 lin.m/m² at 115mm gauge (vertical)
  • Batten Size Recommended 38mm x 25mm for rafters/supports not exceeding 600mm centres
  • Tile Nails 38mm x 2.65mm
