RHEINZINK SP-Line is a prePATINA blue grey zinc facade panel system designed for cladding external walls, dormers, fascias, and gable walls. Panels can be installed horizontally, vertically, or diagonally, using a concealed attachment system with self-drilling screws and coordinated connection profiles for corners and terminations.

  • Prefabricated zinc panel system for external wall cladding
  • Panels allow horizontal, vertical, or diagonal installation
  • Concealed fixing system with included self-drilling screws
  • Prefabricated connection and termination profiles for easy detailing
  • Durable and environment-friendly material protects building structure
  • Panels can be adapted for use around windows and architectural details
  • Waste-free installation possible with 3000 mm panel length

Applications

  • Cladding commercial building facades
  • Residential wall cladding
  • Dormers and roof upstands
  • Fascias and gable walls
  • Multi-storey facade projects

Dimensions

Construction width 350 mm

Panel length 3000 mm

Metal thickness 0.7 mm

Materials

Made from RHEINZINK prePATINA blue grey zinc

Installation

Panels fixed with self-drilling screws in upper area, concealed by next row

Suitable for substructures of wood, aluminium (2.0 mm), or steel (1.5 mm)

Panels assembled from bottom to top for horizontal installation
