TORMAX T1 Series swing door visible drive systems are automatic swing door solutions designed for secure, barrier-free access in public and commercial buildings. Suitable for retrofitting to existing doors, these systems support both visible and concealed drive options, with flexible installation for single or double leaf doors and a range of opening types.

  • Automatic swing door system for easy, secure access

  • Compatible with fire, smoke, hermetic, sound-proof, and radiation-proof doors

  • Push & Go function for simple activation

  • Manual operation possible during power failure

  • Supports access control and building automation integration

  • Independent programmable movement sequences

  • Designed for quick installation and retrofitting

Visible Drive Solutions

In the case of visible drive solutions the drive box and the linkage can be seen externally. They can be quickly connected to existing conventional doors with little effort, which makes them an ideal solution particularly for retro-fitting to doors in public buildings, for example.

Applications

  • Hotels

  • Restaurants

  • Shopping malls

  • Shops

  • Office buildings

  • Hospitals

  • Care homes

  • Schools, theatres, and concert halls

Options and variations

Visible or concealed drive solutions; single or double leaf; left or right opening; multiple linkage types; compatible with various door types including fire, smoke, and hermetic doors.

Optional Areas of Use

  • Fire and smoke doors

  • Smoke extraction

  • Emergency and rescue routes

  • Hermetic doors

  • Sound-proof doors

  • Radiation-proof doors

  • Minergie doors

  • Barrier-free construction

Additional Functions

  • Push & Go: brief pressure from the hand is sufficient to make the door leaf open automatically.

  • Door closing function: simple manual operation is possible during a power failure.

  • Air-lock and porch function: two coordinated doors control access or prevent the exchange of air between the interior and the exterior.

  • Access control: access to the building is monitored by a key, badge, video or biometric data.

  • Building automation: integration into existing building management systems possible.

  • Two independent movement sequences: two movement sequences can be programmed which are independent of each other and which can be activated using different encoders.

  • Wind exposure / environmental influences: the movement sequence remains unchanged and is quite independent of changes to the temperature and wind.
