Tommafold provides high build quality with a flexible and practical system that delivers simple operation and large load capacities whilst being easy to fit and adjust. It features smooth handles, compact track and flush bolts and will blend into both traditional and contemporary settings.

Tommafold bi-folding internal / external door gear is manufactured using high-quality 316 grade stainless steel and is available in a choice of polished stainless, satin stainless, polished brass or Antique black finishes.

Features

  • Top hung bi-folding door system
  • Suited to interior and exterior applications
  • 10-year warranty
  • Smooth rolling polymer tyres tested to 100,000 cycles
  • Hinges tested to 200,000 cycles
  • Track is soffitfixed to underside of jamb
  • Roller connected to door via heavy-duty flush hinge
  • Suitable for timber or metal doors
  • Track can be joined by butting track together
  • Any number of doors can be fitted to the system
  • Compact top track (38 x 39mm)
  • Ergonomic hinge handle design for optimal functionality
  • Ideal for room dividers in homes, offices and hotels

Specifications

  • Max door weight: 120kg
  • Max door height: 4000mm
  • Max door width: 1000mm
  • Min door thickness: 38mm
  • Opening direction: outward; inward
  • Doors to left and right: 1-5
  • Finish: satin stainless steel; polished brass; black
  • Door height: 2.56-3; 2.16-2.55; up to 2.15
  • Top and bottom track length: 2, 3, 4 or 6m
