Evo – Single Pocket Door Kit for Standard Size Doors is a top-hung sliding system designed for fitting a single interior pocket door into drywall, with adjustable frame and smooth nylon rollers. Suits timber, metal, or glass panel doors, with options for soft close and open mechanisms.

  • Sliding pocket door kit for standard interior doors
  • Adjustable frame with click-together assembly
  • Supports door weights up to 120kg (40kg with soft close)
  • Compatible with timber, metal, or glass doors (glass kit available)
  • Includes timber jamb kit and architrave
  • Rollers tested to 100,000 cycles
  • Up to 10mm vertical adjustment

Applications

  • Residential interiors
  • Commercial interiors
  • Drywall partition walls
  • Space-saving door installations

Dimensions

Door size: 610mm x 1981mm
Door size: 686mm x 1981mm
Door size: 762mm x 1981mm
Door size: 838mm x 1981mm
Door size: 726mm x 2040mm
Door size: 826mm x 2040mm
Door size: 926mm x 2040mm
Finished wall thickness: 100mm or 125mm
Door thickness: 35mm – 44mm

Performance

Maximum door weight: 120kg
Maximum door weight with soft close: 40kg
Rollers tested to 100,000 cycles
Up to 10mm vertical adjustment

Installation

For drywall installations
Track is soffit fixed
Click-together frame assembly
Includes all fixings and support framework
