Product name CUPA 12
Material Natural slate
Conforms to BS EN 12326-1:2004
Dimensions (l x w) Between 20x15 and 60x45cm
Thickness (mm) 3.5, 5 and 6mm




CUPA 12 roof slates are made from non-carbonated slate formed by tectonic compression.

  • Colour: grey
  • Surface: smooth matt
  • Sizes: between 20x15 and 60x45cm
  • Format: normally rectangular; other options available
  • Average thickness: 3.5, 5 and 6mm
  • Water absorption: 0.16% code: W1 (< 0.4%)
  • Carbonate non-carbonated: 0.23% fulfill (<1.5%)
  • Mor characteristic: longitudinal 55 MPA; transverse 56 MPA
  • SO2 exposure test: S1
  • Thermal cycle test: T1
  • Freeze thaw test: fulfill <0.6%
  • Origin: Quarry La Campa, Folgoso del Caurel (Lugo), Spain

As this is a natural product it is possible that there will be a shade variation.


CUPA 12 roof slates are made from non-carbonated slate formed by tectonic compression.

  • Colour: grey
  • Surface: smooth matt
  • Sizes: between 20x15 and 60x45cm
  • Format: normally rectangular; other options available
  • Average thickness: 3.5, 5 and 6mm
  • Water absorption: 0.16% code: W1 (< 0.4%)
  • Carbonate non-carbonated: 0.23% fulfill (<1.5%)
  • Mor characteristic: longitudinal 55 MPA; transverse 56 MPA
  • SO2 exposure test: S1
  • Thermal cycle test: T1
  • Freeze thaw test: fulfill <0.6%
  • Origin: Quarry La Campa, Folgoso del Caurel (Lugo), Spain

As this is a natural product it is possible that there will be a shade variation.
