True to Tradition

  • 400 minimum pitch
  • Available with traditional handmade fittings and decorative accessories
  • A natural product with A+ environmental credentials (BREEAM)
  • Frost tested to BS EN 539-2
  • Manufactured from Etruria Marl, considered the finest quality for strength and durability
  • Available in Loxleigh Colour

Nothing compares to handmade clay roof tiles. That's why our new Canterbury handmade roof tiles are created true to tradition.

The traditional handmaking process ensures that each tile is as unique as the hands that made them. Available in three colours with a range of traditional fittings they are perfect for premium roofs and heritage work where only genuine handmade clay plain tiles may be specified to meet planning requirements.

Technical data

  • Size of Tile 265mm x 165mm
  • Minimum Pitch 40°
  • Maximum Pitch 90°
  • Minimum Headlap 65mm (roof) 35mm (vertical)
  • Maximum Gauge 100mm (roof) 115mm (vertical)
  • Cover Width 165mm (nominal)
  • Covering Capacity 60 tiles m² at 100mm gauge (roof) 53 tiles m² at 115mm gauge (vertical)
  • Weight of Tiling 74 kg/m² (0.73kN/m2) at 100mm gauge (roof) 66 kg/m² (0.64kN/m2) at 115mm gauge (vertical)
  • Battens Required 10.0 lin.m/m² at 100mm gauge (roof) 8.7 lin.m/m² at 115mm gauge (roof)
  • Batten Size Recommended 38 x 25mm for rafters/supports not exceeding 600mm centres (fixed to BS 5534)
  • Tile Nails 38mm x 2.65mm
