Modular, reusable fireproof screens made from 80mm-thick steel-faced, mineral wool-filled panels, certified to EN 13501-2:2008 A2 s1 d0 and EI60 for 60-minute fire resistance.

Designed for quick floor-to-ceiling or free-standing installation, these panels suit indoor and outdoor construction site partitioning and weatherproofing.

Features and benefits

  • 60-minute fire rating to EN 13501-2:2008 A2 s1 d0 and EI60

  • Quick modular installation with tongue-and-groove push fit

  • Reusable and relocatable for multiple project phases

  • Range of panel heights for flexible site use

  • Thermal and acoustic insulation

  • Optional doors, vision panels, and windows

Applications

  • Temporary site rooms and offices

  • Fire-rated partition walls

  • External hoarding for weatherproofing

  • Welfare facilities on construction sites

Physical attributes

  • Panel heights: 2.25m, 2.7m, 3.1m (free-standing); 3.5m, 4.0m, 4.5m (floor-to-ceiling)

  • Panel width: 1m.

  • Thickness: 80mm

  • Weight: 17.9 kg/m²

Materials

Made from white steel composite with mineral wool core.

Finish

Pure white (RAL9010).

Options and variations

Doors, vision panels and windows available for custom configurations.

Performance

Fire resistance: 60 minutes (EN 13501-2:2008 A2 s1 d0, EI60). Thermal insulation: U-Value 0.5 W/m²K. Acoustic insulation for noise reduction.

Installation

Floor-to-ceiling with u-channel fixings or free-standing with universal supports. No skilled labour required; installation guide included.
