Material Zinc
Format Strip roofing system
Fixing Fully supported
Minimum roof pitch (deg)
Dimensions (mm) Widths - 400-600mm; thickness - 0.7 or 0.8mm; panel lengths - up to 25m




The Rheinzink® click roll cap roofing system is suitable for pitched roofs from 3° with no additional sealing required.

With the system, courses and protective caps are produced ex works up to 6m in length, in a single process. For production of longer courses, mobile roll shapers are available on loan.

Features / benefits

  • Perfectly fitting components.
  • Reduced tool and machine use.
  • Time-saving surface assembly.
  • Rainproof long seam connection from 3° slope.
  • Wooden rail replacement including binding with binding strips.
  • Course lengths up to 20m.
  • Extreme efficiency, especially for non-ventilated roof superstructures.
  • Higher level of pre-finishing simplifies calculation.


The Rheinzink® click roll cap roofing system is suitable for pitched roofs from 3° with no additional sealing required.

With the system, courses and protective caps are produced ex works up to 6m in length, in a single process. For production of longer courses, mobile roll shapers are available on loan.

Features / benefits

  • Perfectly fitting components.
  • Reduced tool and machine use.
  • Time-saving surface assembly.
  • Rainproof long seam connection from 3° slope.
  • Wooden rail replacement including binding with binding strips.
  • Course lengths up to 20m.
  • Extreme efficiency, especially for non-ventilated roof superstructures.
  • Higher level of pre-finishing simplifies calculation.





Downloads
  • Roofing: system solutions for roofs
    Roofing: system solutions for roofs
    12pp 2.21MB
    Download
  • Design Recommendations for Roof Coverings
    Design Recommendations for Roof Coverings
    1.98MB
    Download



Enquire
