System suitability External walls
Rainscreens
Materials Zinc
Features Secret fixed




The Reveal panel is available in a choice of bay widths from 200-333mm, and in variable joint widths from 0-30mm.

They can be installed in diagonal, horizontal and vertical directions, and in combinations of these, giving the architect freedom when implementing design ideas. A diverse range of building designs can be achieved.

Features and benefits

  • Interesting, visually striking facade structure.
  • Durable weather protection for the building.
  • Provide rear-ventilated curtain walls.
  • Rounded surfaces also achievable.
  • Simple and quick installation, using the tongue and groove principle.
  • Concealed fixing.
  • Available in four distinct finishes: PATINA Line, PROTECT Line, COLOR Line and INTERIEUR Line.


The Reveal panel is available in a choice of bay widths from 200-333mm, and in variable joint widths from 0-30mm.

They can be installed in diagonal, horizontal and vertical directions, and in combinations of these, giving the architect freedom when implementing design ideas. A diverse range of building designs can be achieved.

Features and benefits

  • Interesting, visually striking facade structure.
  • Durable weather protection for the building.
  • Provide rear-ventilated curtain walls.
  • Rounded surfaces also achievable.
  • Simple and quick installation, using the tongue and groove principle.
  • Concealed fixing.
  • Available in four distinct finishes: PATINA Line, PROTECT Line, COLOR Line and INTERIEUR Line.
